SNC200C

CURRENT POSITION: HOME > SNC200C

SNC200C
Product type:
Views:
  • Details
  • Specifications

SNC200C is a localized  inertial measurement unit based on Micro-Electro Mechanical System(MEMS) with built-in high performance MEMS gyro and MEMS accelerometer, which outputs three angular velocities and three accelerations.

SNC200C has high reliability and strong environmental adaptability.  By matching different software, the product can be widely used in autonomous driving, UAV and other fields.


 Physical Dimensions and Electrical Index

 Voltage

 5v

 Power Consumption

 ≤1.5W

 Size

 58.7mm×42mm×8mm

 Weight

 ≤30g

 Environmental Index

 Working Temperature

 -40℃~+70℃

 Storage Temperature

 -45℃~+75℃

 Vibration

 20~2000Hz6.06g

 Shock

 500g0.5ms

 MTBF

 >20000h

 Continuous Working Time

 >120h

 Interface Features

 LVTTL

 System Performance Index

 Parameters

 Test Conditions

 Index

 Gyro

 Range


 1000°/s

 Bias Stability

 10s-40℃~+70℃

 30°/h@10s

 Zero Bias

 Bias Range

 0.3°/s

 Bias Drift at Changing Temperature

 ±0.1°/s

 Start Repeatability

 50°/h

 Vibration Affects Bias

 20°/h/g

 Scale Factor Non-linearity

 500ppm

 Bandwidth

 200Hz

 Accelerometer

 Range

 16g

 Bias Stability-40℃~+70℃10s

 1mg

 Zero Bias

 Bias Range

 5mg

 Bias Drift at Changing Temperature

 5mg

 Scale Factor Non-linearity

 500ppm

 Bandwidth

 200Hz

 Other

 Startup Time

 2s

 Time Delay

 10ms
