Physical Dimensions and Electrical Index |
Voltage | 11-36V |
Power Consumption | ≤8W |
Size | 111mm×72mm×43mm |
Weight | ≤500g |
Environmental Index |
Working Temperature | -40℃~+60℃ |
Storage Temperature | -45℃~+70℃ |
Vibration | 5~2000Hz,6.06g(With Shock Absorption) |
Shock | 30g,11ms(With Shock Absorption) |
Lifetime | >15 Years |
Continuous Working Time | >24h |
Interface Features |
RS422×1 |
RS232×2 |
PPS×1 |
System Performance Index |
| Test Conditions | Index |
Position Accuracy | External GNSS Valid,Single Point | Superior to External Satellite Position Accuracy |
External GNSS Valid,RTK | Superior to External Position Accuracy |
Position Maintenance of Pure Inertial Level | 300m/6min(CEP) |
2nm/20min(CEP) |
Airspeed Combination Horizontal Positioning Maintenance | 1nm/20min (CEP) |
Heading Accuracy | Single Antenna | 0.1°(RMS)(Vehicle Condition, Maneuvering) |
Dual Antenna | 0.2°/L(L is Baseline)(RMS) |
Heading Maintenance | 1°/h(RMS) |
Self-North Seeking Accuracy | 1°SecL, Align for 15min(Dual Position Alignment) |
Attitude Accuracy | GNSS Valid | 0.05°(RMS) |
Attitude Maintenance(GNSS Invalid) | 1°/h(RMS) |
Speed Accuracy | GNSS Valid, Single Point L1/L2 | No lower than the Positioning Accuracy of External Satellites |
